Technical Data
Nominal Voltage: 300V/500V
Temperature Range: -60ºC~+180ºC
Testing Voltage: 2000V
Conductor: Bare or Tinned Copper
Insulation: Silicone Rubber
Sheath: Fiber Glass
Color: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
Certificate: 40016706
Application: Inner wires of electric appliances,lighting fixtures, industrial machines,electric heating products and etc..
| Quantity: | |
|---|---|
Technical Data
Nominal Voltage: 300V/500V
Temperature Range: -60ºC~+180ºC
Testing Voltage: 2000V
Conductor: Bare or Tinned Copper
Insulation: Silicone Rubber
Sheath: Fiber Glass
Colors: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
Certificate: 40016706
Application: Inner wires of electric appliances,lighting fixtures, industrial machines,electric heating products and etc..
Specification
Conductor | Insulation/Sheath | Resistance at 20℃ | |||||
Nominal section | Nominal thickness | Fiber glass thickness | Nominal thickness | Fiber glass thickness mm | Nominal outer diameter | Max outer diameter | |
0.5 | 20/0.18 | 0.94 | 0.6 | 0.15 | 2.4 | 2.6 | 40.100 |
0.75 | 42/0.15 | 1.13 | 0.6 | 0.15 | 2.6 | 2.8 | 26.700 |
1.0 | 32/0.20 | 1.31 | 0.6 | 0.15 | 2.8 | 3.0 | 20.000 |
1.5 | 30/0.25 | 1.58 | 0.7 | 0.18 | 3.3 | 3.6 | 13.700 |
2.5 | 49/0.25 | 2.06 | 0.8 | 0.18 | 4.0 | 4.3 | 8.210 |
4 | 56/0.30 | 2.60 | 0.8 | 0.20 | 4.6 | 5.0 | 5.090 |
6 | 84/0.30 | 3.60 | 0.8 | 0.20 | 5.6 | 6.0 | 3.390 |
10 | 84/0.40 | 4.60 | 1.0 | 0.25 | 7.1 | 7.7 | 1.950 |
16 | 126/0.40 | 5.50 | 1.0 | 0.25 | 8.0 | 8.6 | 1.240 |
25 | 196/0.40 | 7.30 | 1.2 | 0.30 | 10.3 | 11.1 | 0.795 |
35 | 276/0.40 | 8.50 | 1.2 | 0.30 | 11.5 | 12.4 | 0.565 |
50 | 396/0.40 | 10.30 | 1.4 | 0.35 | 13.8 | 14.9 | 0.393 |
70 | 360/0.40 | 12.40 | 1.4 | 0.35 | 15.9 | 17.2 | 0.277 |
95 | 475/0.50 | 14.50 | 1.6 | 0.40 | 18.5 | 20.0 | 0.210 |
Application Area
Packaging & Shipping
Manufacturing Shop
Certifications
We have the certifications of UL, VDE, CCC, ISO9001, IATF 16949，CE.
