Technical Data
Temperature Range: 105℃
Conductor: 0.5 ~ 6mm² Strand, Bare Copper
Insulation: PVC
Standard: VW60306
Application: For internal wiring of automotive meters' circuits and electrical equipment in high-temperature area.
Specification
Nominal Cross Section mm² | Conductor Structure | Min. Insulation Thickness | Cable Outer Diameter | Rerference Weight | Max. Resistance at 20℃ | ||
Min. | Max. | Copper | Tinned Copper | ||||
0.5 | 16/0.20 | 0.44 | 2 | 2.3 | 9 | 37 | / |
1 | 32/0.20 | 0.44 | 2.4 | 2.7 | 15 | 18.3 | / |
1.5 | 21/0.30 | 0.44 | 2.7 | 3 | 20 | 12.5 | / |
2.5 | 35/0.30 | 0.53 | 3.3 | 3.7 | 31 | 7.5 | / |
4 | 56/0.30 | 0.62 | 4 | 4.5 | 49 | 4.6 | / |
6 | 19/0.64 | 0.62 | 4.6 | 5.1 | 71 | 3 | / |
84/0.30 | 69 | / | |||||
Application Area
Packaging & Shipping
Manufacturing Shop
Certifications
We have the certifications of UL, VDE, CCC, ISO9001, IATF 16949，CE.
FAQ:
1.Q: Are you trading company or manufacturer ?
A:We are factory, with the belief "Good faith makes quality, Good quality wins market".
2.Q: How long is your delivery time?
A:Generally it is 5-10 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to order quantity.
3.Q:What certifications do you have?
A:We have ISO9001 , IATF16949 , UL, CUL, VDE, RoHS, REACH and SGS for our wires & cables.
3.Q:What is your payment term?
A:We have several payment terms for you, T/T, Western Union, L/C, etc.
4.Q:Can you do the design for us?
A:Yes, we have a professional team having rich experience in wire and cable design and manufacturing.Just tell us your demands, we will manufacture the cable as your requirements.
