Technical Data
Nominal voltage: 600V
Temperature Range: -60° C~+200 ° C
Testing Voltage: 2000V
Conductor: Tinned Copper
Insulation: Silicone Rubber
Sheath: Fiberglass
Colors: White-Blue-Red-Black-Brown-Yellow-Transparent
Certificate No.: E216252
Application: Lead wires for Home electric Appliances, lightings, electronic equipment and sensors etc.
Specification
Conductor | Insulation/Sheath | Max Resistence at 20℃ Ω/km | Premissible Ampacity | |||||
AWG | Conductor Structure | Diameter | Nom. Thickness | Figerglass Thickness | Nom. Outer Diameter | Max Outer Diameter | ||
18 | 7/0.39 | 1.17 | 0.78 | 0.15 | 3.0 | 3.3 | 23.0 | 22.02 |
16 | 7/0.49 | 1.47 | 0.78 | 0.20 | 3.4 | 3.7 | 14.6 | 35.04 |
14 | 41/0.25 | 1.82 | 0.78 | 0.20 | 3.8 | 4.1 | 9.9 | 55.68 |
Application Area
Packaging & Shipping
Manufacturing Shop
Certifications
We have the certifications of UL, VDE, CCC, ISO9001, IATF 16949，CE.
