Technical Data
Nominal Voltage: 600V
Temperature Range: -60℃~+200℃
Testing Voltage: 6000V
Conductor: Bare or Tinned Copper
Insulation: Silicone Rubber
Colors: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
UL/CUL Certificate No.: E216252
Application: Inner fixed wires for home electric appliances,lighting fixtures, electronic equipment and etc..
| Quantity: | |
|---|---|
Technical Data
Nominal Voltage: 600V
Temperature Range: -60℃~+200℃
Testing Voltage: 6000V
Conductor: Bare or Tinned Copper
Insulation: Silicone Rubber
Colors: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
UL/CUL Certificate No.: E216252
Application: Inner fixed wires for home electric appliances,lighting fixtures, electronic equipment and etc..
Specification
Conductor | Insulation | Resistance at 20℃ | ||||
AWG | Conductor structure | Diameter | Nominal thickness | Nominal outer diameter | Max. outer diameter | |
0.5 | 28/0.15 | 0.93 | 0.78 | 2.49 | 2.69 | 40.100 |
0.75 | 24/0.20 | 1.13 | 0.78 | 2.69 | 2.91 | 26.700 |
1 | 32/0.20 | 1.31 | 0.78 | 2.87 | 3.10 | 20.000 |
1.5 | 30/0.25 | 1.58 | 0.78 | 3.14 | 3.39 | 13.700 |
2 | 41/0.25 | 1.85 | 0.78 | 3.41 | 3.68 | 9.900 |
2.5 | 49/0.25 | 2.06 | 0.78 | 3.62 | 3.91 | 8.210 |
4 | 56/0.30 | 2.60 | 0.78 | 4.16 | 4.49 | 5.090 |
6 | 84/0.30 | 3.60 | 1.14 | 5.88 | 6.35 | 3.390 |
10 | 84/0.40 | 4.60 | 1.52 | 7.64 | 8.25 | 1.950 |
16 | 126/0.40 | 5.70 | 1.52 | 8.74 | 9.44 | 1.240 |
25 | 196/0.40 | 6.70 | 1.52 | 9.74 | 10.52 | 0.795 |
35 | 276/0.40 | 8.50 | 1.52 | 11.54 | 12.46 | 0.565 |
50 | 396/0.40 | 10.30 | 2.03 | 14.36 | 15.51 | 0.393 |
70 | 560/0.40 | 12.40 | 2.03 | 16.46 | 17.78 | 0.277 |
95 | 760/0.40 | 14.50 | 2.03 | 18.56 | 20.04 | 0.210 |
120 | 955/0.40 | 16.50 | 2.45 | 21.40 | 23.11 | 0.164 |
150 | 1194/0.40 | 18.00 | 2.45 | 22.90 | 24.73 | 0.132 |
185 | 1472/0.40 | 20.50 | 2.45 | 25.40 | 27.43 | 0.108 |
240 | 1910/0.40 | 23.00 | 2.45 | 27.90 | 30.13 | 0.082 |
Application Area
Packaging & Shipping
Manufacturing Shop
Certifications
We have the certifications of UL, VDE, CCC, ISO9001, IATF 16949，CE.
